Roll Body Technical Chart
Center Distance 9 1/4"
234.95 mm
9 3/8"
238.12 mm
9 1/2"
241.30 mm
9 5/8"
244.50 mm
9 3/4"
247.65 mm
9.845"
250 mm
  Break Polish Break Polish Break Polish Break Polish Break Polish Break Polish
No. of Teeth Pinion 22 34 22 34 22 35 23 35 23 36 24 36
No. of teeth Gear 54 42 55 43 56 43 56 44 57 44 57 45
Total No. of Teeth 76 77 78 79 80 81
